Dowel Pin

Absolute Micro-Metric Alignment & Severe Shear Strength

• Uncompromising Interlocking Locating: Specially ground to ultra-tight outer diameter parameters to serve as the structural baseline for multi-plate mold block alignment, eliminating cross-plate shearing errors.
• Elite SUJ2 Bearing Steel Base: Through-hardened to uniform deep specifications, offering high core strength and surface resistance against frictional deformation during high-pressure clamping.
• Ergonomic Chamfering & Extraction: Ends feature precisely calculated lead-in chamfers to guide entry into blind holes. Available with specialized internal pull-out threads for easy toolroom extraction.

Customization & Non-Standard OEM Expertise

• Tailored to Your Drawings: We offer comprehensive OEM/ODM manufacturing flexibility, delivering high-precision dowel pins processed exactly to your provided 2D blueprints (PDF/DXF) and 3D CAD models (STEP/IGS).
• Specialized Structural Footprints: We excel at processing custom extractable layouts, specialized flat air-vent bypass channels, non-standard step tapers, and tailored length constraints that standard fast-ship stocks do not provide.
• Rapid Factory Turnaround: Our highly automated grinding setup minimizes batch manufacturing timelines, ensuring fast product dispatch to meet urgent assembly deadlines.

Technical Specifications

• Dowel Mechanical Variations: Hardened Straight Type, Internal Threaded Extractable Type, Tapered Locating Styles.
• Achievable Tolerances: Outer Diameter (O.D.) tolerance precision-ground down to +0.002mm to +0.007mm (m6 fit classification).
• Structural Core Hardness: Uniformly heat-treated to settle securely at HRC 58-62 for long-term wear resistance.

We are committed to helping industrial buyers, localized workshop managers, and emerging product designers grow by offering flexible purchasing with absolutely no minimum order quantity (MOQ) pressures. Whether you require a hand-tailored set of 10 extractable dowels for specialized fixtures or a large low-volume batch run for new mold platforms, we deliver premium results with minimal stock burden. Contact our engineering team today to upload your drawings and get started.
